DC-DC Converter
1KW DC/DC Converter 96V to 12V
Designed for 96V electric vehicle platforms, this 1.2kW DC/DC converter provides stable 9-16V DC output for vehicle low-voltage systems. Featuring high efficiency, CAN Bus communication and multiple protection functions, it delivers a reliable power solution for commercial EVs, utility vehicles and other electric vehicle applications.
96V 1kW DC/DC Converter for Electric Vehicles
Compact Power Conversion Solution for EV Low-voltage Systems
Echelon Energy’s 96V 1.2kW DC/DC Converter is designed for electric vehicle platforms, providing stable low-voltage power supply from the vehicle battery system.
With 96V battery system compatibility, high efficiency, CAN Bus communication and multiple protection functions, this converter supports reliable operation of auxiliary electrical systems in commercial EVs and special-purpose vehicles.
Key Features
✓ 96V battery system compatible
✓ 1.2kW rated output power
✓ 9-16V DC stable output
✓ High efficiency ≥94%
✓ CAN Bus communication support
✓ Forced air cooling design
✓ Multiple protection functions
Applications
Designed for:
- Electric commercial vehicles
- Electric utility vehicles
- Electric trucks
- Electric agricultural vehicles
- Special-purpose EVs
- Other electric vehicle auxiliary power systems
Stable Power Supply for EV Auxiliary Systems
Electric vehicles require a reliable low-voltage power source to support different electrical components.
This DC/DC converter converts high-voltage battery power into stable 12V-class output, providing power for:
- Vehicle controllers
- Lighting systems
- Instrument panels
- Auxiliary electrical equipment
Reliable Performance & Protection
Designed for demanding EV operating environments, the converter integrates multiple protection functions to improve system safety and reliability.
Protection functions include:
✓ Input over-voltage protection
✓ Input under-voltage protection
✓ Output over-voltage protection
✓ Output over-current protection
✓ Short circuit protection
✓ Over-temperature protection
Technical Specifications
Electrical Parameters
Parameter | Specification |
|---|---|
Model | PD-BC-1A-96Y |
Voltage Platform | 96V DC |
Input Voltage | 64-128V DC |
Input Current | 0-20A |
Output Voltage | 9-16V DC |
Rated Output Current | 72A |
Peak Output Current | 86A |
Rated Power | 1200W |
Peak Power | 1200W (6 minutes) |
Efficiency | ≥94% |
Cooling Method | Forced Air Cooling |
Weight | 2.8kg |
Communication & Integration
The DC/DC converter supports CAN Bus communication, allowing integration with EV control systems.
Designed with compact structure and vehicle mounting capability, it helps OEM manufacturers simplify low-voltage power system design.
Designed for OEM EV Platforms
From prototype development to mass production, Echelon Energy provides reliable DC/DC converter solutions for different electric vehicle applications.
